TEMPERATURE & RH SMART TRANSMITTER CLASSIC FEATURES
- Based on state of art latest microcontroller technology with Watchdog feature for fail safe operation.
- Highly accurate, fast & reliable sensing technology.
- Fixed resolution of 0.1 for both temperature & Relative humidity.
- Long term Stability for %RH is typically < 1% RH / year.
- Excellent long term stability.
- Compact size, easy to install & flexible.
- Optional display / keypad.
- Isolated RS485 Serial port with MODBUS RTU Protcol output for PC interface.
APPLICATIONS:-
It is used in,
- Building automation , climate control rooms, computer server
rooms, green houses.
- Agriculture application, meteorological application,
weather station.
- Humidifiers & Dehumidifiers , electronic enclosure.
- Drying process in chemical application.
- Storage room monitoring, cold storage, clean rooms , warehouse.
- Pharmaceuticals , Medical application (health care, medicine
storage).
- Calibration equipments.
- Industrial process monitoring & controls & etc
Temperature / Humidity / Pressure Data Logger
- Excellent price/performance ratio
- Automatic recording of temperature / humidity / pressure data
- Stores 12 000 readings, can be read off at any time
- No network connection required
- Programming and evaluation with PC
- LED alarm
- Min/max values on display
- Replaceable battery
- Software FDA 21 Part 11-conform
Technical Data
Measuring range -30°C to +60°C / 0 ... 100 %rH / 700 ... 1200 mbar
Accuracy ± 0,5°C (-20°C up to 40°C) ± 0,8 °C for remaining measuring range
Optional (against surcharge): ± 0,2 °C (-20°C bis 40°C) with calibration ±3 %rH (10 to 90% rH)± 5mbar
Resolution 0.1°C Memory 12 000 samples (4 000 spamples per channel)
Sensor NTC / capacitive sensor / absolute pressure sensor
Operating temperature -30°C to +60°C Storage temperature -40°C to +70°C Measuring rate 1 min to 24 h Measuring mode Endless; Until memory full; Start time; Start/Stop time; Start with key
Battery 3 V lithium (CR2450), can be replaced by user Battery life >24
Protection class IP 52
Housing ABS Dimensions 69 x 48 x 22mm
Weight 45 g |
